Sungrow SH Hybrid Inverter 20kW for agriculture, larger detached houses, or housing cooperatives

The Sungrow SHT series is a powerful three-phase hybrid inverter solution for larger households and small commercial properties. The series is designed for applications requiring higher power, extensive battery support, and full backup power capacity.

The SHT series enables whole-property backup power supply and seamless transition between on-grid and off-grid operation without interruptions.

Key features

-Power classes 15, 20 and 25 kW
-Full backup power capability for the entire property
-Multiple MPPT inputs for diverse roof surfaces
-High DC/AC sizing for flexible solar panel field design
-IP65 and C5 rating for demanding environments
-Compatible with Sungrow’s SBR and SBH batteries

Especially suitable for

-Larger detached houses and farms
-Farms and small commercial properties
-Applications requiring reliable backup power and scalability

The package also includes a Wifi module

Technical specifications

• Package sizes: 1 PC/6 PCS
• Max. DC input power: 20kW
• Number of panels: 30kW (150%)
• Number of MPP trackers: 3
• Display: standard
• Max. input current DC per MPP tracker: 80
• Width: 620 mm
• Height: 480 mm
• Depth: 245 mm
• Input voltage DC max: 1000
• Output voltage AC 50 Hz: 20000
• Efficiency (EU): 97.60
• Weight: 38
• Max. efficiency: 98.1
• Short-circuit current max per MPPT: 100 A
• Maximum power point voltage range (MPP): 150-950
• Suitable for emergency power operation: yes
• Enclosure protection class (IP): IP65
• Grid monitoring: 3-phase
• Input voltage type: DC
• Wireless: yes
• Data collection: yes
• Ethernet: yes
• Internal battery: no
• Suitable for outdoor installation: yes
• Integrated DC switch: yes
