Alfen Eve Single S-Line Charging station system for 5 apartments

Alfen Eve Single S-Line charging station. OCPP compatible with Woltti cloud service.

Enables Solar charging, automatic control of charging based on Spot prices and, in the near future, VTG charging.

- 5 Alfen Eve Single S-Line charging stations with a 6-meter cable
- Load management with the Woltti online service or locally
- Ethernet cabling
- Basic installation applied

Alfen Eve Single S-Line max. The 22kW electric car smart charging device is perfectly suited for housing associations, single-family homes, companies or public charging. The charging device is designed to offer smart functions for businesses and home charging. Charging can also be reduced based on electricity metering. A technical and durable charging station equipped with a single cable. Can be mounted on a wall or pole.

Alfen is one of the largest suppliers of charging equipment for public and housing associations in Finland and Europe. Even complex systems can be implemented with the charger, including local load distribution and cloud services. The charging station is OCPP compatible, to which you can connect the Woltti web service or another OCPP web service. With the help of the service, the systems of building societies can be easily managed, for example in terms of invoicing and load management. The Woltti online service includes the Woltti App and a separate invoicing and management view for users, which allows the housing company to easily make invoicing, monitor electricity consumption, add RFID cards and users, and update chargers. Ask more about our sales.

Charge all electric cars at maximum power. Even if your car doesn't support fast charging yet, it's worth a little extra investment now. Cars evolve and this way you don't need a new charging station in the future.

• Model: Alfen Eve Single S-Line T2
• Type: Electric car permanently installed charging device Wallbox for home, company or housing association.
• Connector car: Type2
• Plug: Equipped with a cable but also available with a plug.
• Type2 cable length: 5m or 7.5m (changeable)
• Place of use: Home/household associations/businesses/public smart charging, OCPP compatible
• Current: 32A, 3-Phase. Power can be reduced either locally or as a cloud service.
• Power: 3.7 - 11kW
• Size: 370mm*240mm*130mm
• Weight: 7kg
• Charging method: AC
• Voltage: 230-400V
• Residual current: B residual current detector (to center A)
• Manufacturer: Alfen
• RFID: Option
• MID meter
• Connection method: Ethernet or LTE (SIM already inside)
• Protection level: IP55
• Certificates: CE
• Warranty 2 years (extendable to 5 years)

Ask for the exact conditions of the basic installation if you order the device installed. If you use the cloud service, a separate agreement will be drawn up. More information about the basic installation .

Before installation, make sure that the capacity of the electrical network is sufficient for the charging station. The device can only be installed by an approved electrician. The device can be installed indoors and outdoors.

All our products have a CE certificate.
