Huawei Luna2000 Battery system 5kWh

Use solar energy when you need it

Huawei Luna energy storage systems are perfect for households that want to harness and store free solar energy. The system is modular and scalable, with 1-3 modules, max. 15kW, installed in the same unit.

Huawei energy storage systems increase the energy independence of the house. By adding batteries to the solar power system, you can easily maximize the utilization of the energy produced and improve the profitability of the solar panel system. The whole can be used to easily smooth out consumption peaks and you are self-sufficient even during possible power outages. You can also create smart battery systems that allow you to utilize your own production to charge an electric car.

More useful energy - 100% discharge and energy optimization
Flexible system - 5 kWh modular design, scalable system 5-30 kWh
Safe & Reliable - Lithium Iron Phosphate (LFP) Cell
Quick setup - Automatically appears in the app
Easy installation - 12 kg power module, 50 kg battery module
Perfect Compatibility - Compatible with household 1-phase and 3-phase inverters

Downloadable brochures and instructions

• Huawei Luna2000 Battery Systems brochure ENG (pdf)
• Huawei Luna2000 Battery Systems User Manual ENG (pdf)

Specifications

• Battery nominal capacity: 5kWh
• Battery: Lithium-iron phosphate (LiFePO4)
• Usable battery capacity: 5kWh
• Power output max: 2.5kW
• Short-term peak power output: 3.5kW, 10 s
• Voltage: DC
• Rated voltage: 360V (1-phase) / 600V (3-phase)
• Operating voltage range: 350-560V / 600 – 980V
• Dimensions 600 x 670 x 150 mm (H x W x D)
• Operating temperature: -10 ... +55 °C
• Wifi/Ethernet: No
• Connection: RS458
• Parallel connection: max 2 systems
• Protection rating: IP65
• Weight: 63.8kg

The price includes:

• 1 x Huawei Luna2000 DC/DC Power module CMW594
• 1 x Huawei Luna2000 Battery Module 5kW CMW601
